100W N-JK Male to Female RF Coaxial Attenuator DC-3/4GHz 1-60dB
100W N-JK Male to Female RF Coaxial Attenuator DC-3/4GHz 1-60dB
Couldn't load pickup availability
| Specification | Parameter |
|---|---|
| Model | BC-AT100-01 |
| Power | 100W |
| Connector | N-JK |
| Frequency Range | DC-3GHz/4GHz |
| Attenuation | 1-60dB available, and 1-10dB.±0.5dB,15-30dB±1dB, 40-60dB±1.5dB |
| VSWR (MAX) | 1.2:1 /1.3:1 |
| Impendance | 50Ω |
| Temperature Range | -55°C to +125°C |
| Dimension | 140*50mm |
| Weight | 0.7kg |
